Concept Unification Diagnostics Tape 1

Screenshot of 'Concept Unification 1991 Diagnostics Tape 1'

Release: Mar. 1991 - May 1993

Concept Unification Diagnostics Tape 1 was the first diagnostics tape released for the Concept Unification Stage. This would be used to diagnose any issues with the show. Tape 1 goes over Slate & Dual Pressure Specifications, Chuck E. Cheese, Helen Henny, Mr. Munch, Jasper, Pasqually, and Camera. In May 1993 3-Stage Diagnostic Tape 1993 would replace Concept Unification Diagnostics Tape 1 and Tape 2.

Diagnostics List:

Each Movement is tested for approximately 1 1/2 Minutes. Movement test is in order of the valve banks.

1. Chuck E. Cheese
   1. Mouth
   2. Ears
   3. Eye Lids
   4. Eyes Left
   5. Eyes Right
   6. Head Left
   7. Head Right
   8. Head Up
   9. Left Arm Raise
   10. Left Arm Twist
   11. Left Elbow
   12. Right Arm Raise
   13. Right Arm Twist
   14. Right Elbow
   15. Body Twist Left
   16. Body Twist Right
   17. Body Lean
2. Helen Henny
   1. Mouth
   2. Feather Pig Tails
   3. Eye Lids
   4. Eyes Left
   5. Eyes Right
   6. Head Left
   7. Head Right
   8. Head Up
   9. Left & Right Arm Raise
   10. Left & Right Elbows
   11. Left & Right Arm Twist
   12. Body Twist Left
   13. Body Twist Right
   14. Body Lean
3. Mr. Munch
   1. Mouth
   2. Eye Lids
   3. Eyes Left
   4. Eyes Right
   5. Head Turn Left
   6. Head Turn Right
   7. Head Tilt Left
   8. Head Tilt Right
   9. Head Up
   10. Left & Right Arm Swings
   11. Left & Right Elbows
   12. Foot Tap
   13. Body Lean
4. Jasper T. Jowls
   1. Mouth
   2. Eye Lids
   3. Eye Cross
   4. Head Left
   5. Head Right
   6. Head Up
   7. Right Arm Raise
   8. Right Arm Twist
   9. Right Elbow Twist (Strum motion)
   10. Right Wrist Out
   11. Left Hand Slide
   12. Guitar Raise
   13. Leg Raises
   14. Body Lean
5. Pasqually
   1. Mouth
   2. Eye Lids
   3. Eyes Left
   4. Eyes Right
   5. Head Left
   6. Head Right
   7. Head Up
   8. Left Arm Swing
   9. Right Arm Swing
   10. Left & Right Elbows
   11. Hi Hat (foot combo)
   12. Body Lean
6. Camera
   1. Mouth
   2. Eye Lids
   3. Eyes Cross
   4. Head Right
   5. Mech Raise
