An official procedure for cylinder rebuilding is documented in the ShowBiz Pizza Place Operations Manual from 1981.
Remove front or rear face of cylinder
Remove piston
Remove nose seal and ‘O’ rings
Clean all parts with a clean rag and denatured alcohol
Coat piston and new seals with packer lube
Install the new ‘O’ rings (flanges facing each other)
Coat the cylinder wall with parker ‘O-ring’ lube
Lube piston rod with 10 weight non-detergent oil
Reassemble NOTE: It is advisable to rebuild the cylinder on a clean piece of paper or newspaper. This will help prevent foreign matter finding its way inside your newly rebuilt cylinder.
